Unshaped refractory Silica Refractory

  • Sticking time: 1-3min
  • Bulk density : 2.1g/cm3
  • Granularity : ≥0.2mm
  • Refractoriness: 1710℃
email.png livechat.png
Share With :
  • Silica Brick
  • Silica Brick
  • Silica Brick
■ Feature

Silica hot patch refractory is a repair cement used to repair and seal door jambs in coke ovens.
Refractory cement for in situ hot repair of the sole of coke ovens. This material is supplied dry and mixed on site and pumped into the oven. It can be spread along a sole of the oven using recoke push bar and allow to self level. Maximum service temperature 1400°C.
White ready mixed, refractory air setting mortar. Maximum service temperature 1425°C. Refractory mortar is also as known as joint filler, it is composed of a certain particle ratio of refractory powder, binder and additive, pour water or liquid binder to tune into a paste. Silica mortar is an important part of refractory mortar which is as Cab-O-sil or adding some ganister sand as main raw materials, the binder adopts mild-clay or chemical bond.

Application:
Silica mortar is mainly used for laying and repair of coke oven, hot blast stove, glass melting furnace, melting furnace and other masonry of high quality silica bricks industrial furnace.

Features:

1.High adhesive strength.
2.High refractoriness.
3.Excellent refractoriness under load.
4.Good installation performance.

Mixing sequence:

1. The silica mortar is the fine powder (0.088mm). Put the mortar in to the mixer and spray the small bag of additives on the dry powder evenly, mix them for 3 to 5min. Next, put 32 to 35 per cent of clean water (tap water and water amount can be adjusted according to actual conditions) into it and continue mixing for 5 to 10min. The effect will be better if you put the mortar slurry static for 10min. Amount of agitation should be determined according to the capacity of mixer. But it must be used by the bag.
2. The mortar well mixed should be used as soon as possible for fear of loosing effectiveness.
Attention: it is prohibited to put the additives into the water separately; it is prohibited to use acid industrial waste water to mix the slurry; operate strictly according to the requirements, or else it will influence the masonry quality and useful life of the mortar.


■ Technical Data





Unshaped refractory Silica Refractory

Silica Mortar

Silica hot patch refractory

BGN-94

BGN-95

BGN-96

RB

SiO2

94

95

96

90

Al2O3

1.0

1.0

0.6

-

Fe2O3

1.0

1.0

0.7

-


Bonding strength Mpa

110 x 24h

0.8

0.8

0.8

-

1400 x 3h

0.8

1.0

0.5


Bonding time
Min

2~3

1~3

1~3

-


Bulk density
g/cm3

-

-

-

1.8


After reheating linear change1500℃X3h)(%

-

-

-

-0.5~+2.0


Cold crushing strengthMPa

-

-

-

35



Grain size
%


+0.5mm

2.0

2.0

2.0

-


-0.074mm

60

60

60



焦炉,热风炉用硅质泥浆
Silica Mortar for coke oven






Unshaped refractory Silica Refractory

Silica Mortar for coke oven

Silica Mortar for blast stove

JGN-85

JGN-92

RGN-94


SiO2

85

92

94


Fe2O3

-

-

1.0


Refractoriness, Cone No.

158

156

170




Cold Rupture Bonding strength Mpa


≥Drying at 110


1.0

1.0

1.0


Firing at 1400 x 3h

3.0

3.0

3.0


Bonding timeMin

1~2

1~2

1~2


0.2MPa refractoriness under loadT 0.6

1420

1500

1600



Grain size
%


+0.5mm

3.0

3.0

1.0


-0.074mm

50

50

60
